Análisis del ciclo de vida de las medidas preventivas a la corrosión aplicadas a puentes pretensados

Acaban de publicarnos un artículo en la revista Environmental Impact Assessment Review (primer decil del JCR), de la editorial ELSEVIER, en el que se realiza una valoración de las medidas preventivas consideradas en el proyecto a lo largo del ciclo de vida de un puente de hormigón sometido a un ambiente costero, donde los clorhídricos suponen una agresión que supone un mantenimiento de la infraestructura. En el artículo se analizan 15 diseños diferentes y se comprueba que no siempre realizar un mantenimiento mínimo supone menores impactos ambientales. Además, los tratamientos superficiales y la adición de humo de sílice supone una reducción del 70% en los impactos.

Además, la editorial ELSEVIER nos permite la distribución gratuita del artículo hasta el 6 de agosto de 2018. Por tanto, os paso el enlace para que os podáis descargar este artículo: https://authors.elsevier.com/a/1XERB3QCo9R2ye

Referencia:

NAVARRO, I.J.; YEPES, V.; MARTÍ, J.V.; GONZÁLEZ-VIDOSA, F. (2018). Life cycle impact assessment of corrosion preventive designs applied to prestressed concrete bridge decks. Journal of Cleaner Production, 196:698-713. https://doi.org/10.1016/j.jclepro.2018.06.110

Abstract:

Chloride corrosion of reinforcing steel in concrete structures is a major issue in the construction sector due to economic and environmental reasons. Assuming different prevention strategies in aggressive marine environments results in extending the service life of the exposed structures, reducing the maintenance actions required throughout their operation stage. The aim of the present study is to analyze the environmental implications of several prevention strategies through a life cycle assessment using a prestressed bridge deck as a case study.

The environmental impacts of 15 prevention alternatives have been evaluated when applied to a real case of study, namely a bridge deck exposed to a chloride laden surrounding. The Eco-indicator 99 methodology has been adopted for the evaluation of the impacts. As some of the alternatives involve the use of by-products such as fly ash and silica fume, economic allocation has been assumed to evaluate their environmental impacts.

Results from the life cycle analysis show that the environmental impacts of the chloride exposed structure can be reduced significantly by considering specific preventive designs, such as adding silica fume to concrete, reducing its water to cement ratio or applying hydrophobic or sealant treatments to its surface. In such scenarios, the damage caused to the environment mainly due to maintenance operations and material consumption can be reduced up to a 30–40% of the life cycle impacts associated to a conventional design. The study shows how the application of life cycle assessment methodologies can be of interest to reduce the environmental impacts derived from the maintenance operations required by bridge decks subjected to aggressive chloride laden environments.

Keywords:

Life cycle assessmentChloride corrosionPreventive measuresEco-indicator 99Bridge deckSustainable designConcrete

Highlights:

  • Life cycle assessment of different design strategies for bridge decks in marine environments.
  • 15 different design alternatives were studied and compared with the conventional design.
  • Less maintenance does not always result in lower environmental impacts.
  • Steel and maintenance are main contributors to environmental burdens.
  • Surface treatments and the addition of silica fume reduce impacts up to 70%.







Valoración social del ciclo de vida de un puente en un ambiente agresivo

Acaban de publicarnos un artículo en la revista Environmental Impact Assessment Review (primer decil del JCR), de la editorial ELSEVIER, en el que se realiza una valoración del impacto social a lo largo del ciclo de vida de un puente de hormigón sometido a un ambiente costero, donde los clorhídricos suponen una agresión que supone un mantenimiento de la infraestructura.

En el trabajo se analizan 15 alternativas diferentes durante el mantenimiento en relación con los impactos sociales. Los resultados indican que el uso de acero inoxidable en las armaduras y la adición de humo de sílice son preferibles a otras alternativas convencionales. Os dejo a continuación el resumen y las conclusiones.

Además, la editorial ELSEVIER nos permite la distribución gratuita del artículo hasta el 11 de julio de 2018. Por tanto, os paso el enlace para que os podáis descargar este artículo: https://authors.elsevier.com/a/1X5QpiZ5swxFZ

Referencia:

NAVARRO, I.J.; YEPES, V.; MARTÍ, J.V. (2018). Social life cycle assessment of concrete bridge decks exposed to aggressive environments. Environmental Impact Assessment Review, 72:50-63. https://doi.org/10.1016/j.eiar.2018.05.003

Abstract:

Sustainable design of structures includes environmental and economic aspects; social aspects throughout the life cycle of the structure, however, are not always adequately assessed. This study evaluates the social contribution of a concrete bridge deck. The social performance of the different design alternatives is estimated taking into account the impacts derived from both the construction and the maintenance phases of the infrastructure under conditions of uncertainty. Uncertain inputs related to social context are treated through Beta-PERT distributions. Maintenance needs for the different materials are estimated by means of a reliability based durability evaluation. Results show that social impacts resulting from the service life of bridges are not to be neglected in sustainability assessments of such structures. Designs that minimize maintenance operations throughout the service life, such as using stainless steel rebars or silica fume containing concretes, are socially preferable to conventional designs. The results can complement economic and environmental sustainability assessments of bridge structures.

Keywords:

Social life cycle assessmentChloride corrosionPreventive measuresGuidelinesConcrete bridgeSustainable design

Highlights:

  • Social Life Cycle Assessment of different design strategies for bridge decks in marine environments.
  • 15 design alternatives were studied and compared according to the Guidelines methodology.
  • Less maintenance results in better social performance.
  • Impacts during maintenance phase are main contributors to social performance
  • Stainless steel and the addition of silica fume are socially preferable to conventional designs.







Towards sustainable civil engineering works using precast concrete solutions

CV ARTICULOMost of the achieved advances related to define standardized methodologies to quantify the contribution to “sustainabilize” the construction are linked to buildings rather than infrastructures, and much more in particular to housing. Global impact on housing is the widest and highest one, gathering the three sustainable axis: environmental (greenhouse gas emissions derived from heating or cooling to reach indoor comfort  conditions), social (home is a basic need for families) and economic (it usually represents the main expense over the life of people). Meanwhile civil engineering work has not evolved as long on this topic. Although we generally refer to greater constructions, sustainable impacts are more diffused and don´t have such a direct repercussion into the citizens and daily life. For this reasons, there are not as many assessment methods for civil engineering works as there are for buildings, or even any literature regarding this field. Therefore it may implies a technical and promotional handicap to promote a higher use of precast concrete elements in a sort of constructions governed by engineers that usually appreciate better their performance advantages. This article pretends to describe the strengths that precast concrete construction will have into the upcoming standards for civil engineering works, in order to enhance their possibilities to reach a greater market share. Sustainable indicators on current draft standards will be assessed.

Reference:

López-Vidal, A.; Yepes, V. (2015). Towards sustainable civil engineering works using precast concrete solutions. Concrete Plant International, 5: 18-24. (link)

Descargar (PDF, 2.31MB)

10 noviembre, 2015

|   Etiquetas: ,  ,  ,  ,  |

Cost and CO2 emission optimization of precast-prestressed concrete U-beam road bridges by a hybrid glowworm swarm algorithm

Esta es la versión post-print de autor. La publicación se encuentra en: http://dx.doi.org/10.1016/j.autcon.2014.10.013, siendo el Copyright de Elsevier.

El artículo debe ser citado de la siguiente forma:

Yepes, V.; Martí, JV.; García-Segura, T. (2015). Cost and CO2 emission optimization of precast prestressed concrete U-beam road bridges by a hybrid glowworm swarm algorithm. Automation in Construction. 49:123-134. doi:10.1016/j.autcon.2014.10.013.

Descargar (PDF, 1.04MB)
